BTL5-P/I/K/L/M_-M/U_ _ _ _-P-S32/KA_ _
Micropulse Linear Transducer
Digital Output / Profile Housing
7 Technical Data
The following are typical values at DC 24 V and 25 °C. Fully operational after power-up, with full accuracy after
warm-up. Values are with BTL5-P-3800-2, BTL5-P-4500-1 or BTL5-P-5500-2 magnet held at a constant
offset from the transducer or with captive magnet BTL5-F/M/N-2814-1S (see magnet section for exceptions):
Resolution < 2 µm
Hysteresis < 4 µm
Repeatability < 6 µm
(resolution + hysteresis)
System resolution (BTL5-.... + BTA)
is determined by the processor or
external controller.
Recommended sampling rate:
Nominal length f
Standard
< 1000 mm 0.5 to 2 kHz
< 2000 mm 0.5 to 1 kHz
> 2000 mm 0.5 kHz
Non-linearity:
Nom. length < 500 mm > 500 mm
±100 µm ±0.02 %
Temperature coefficient
< (6 µm + 5 ppm
*
nominal length)/K
Shock loading 100 g/6 ms
per IEC 68-2-27
1
Continuous shock 100 g/2 ms
per IEC 68-2-29
1
Vibration 12 g, 10 to 2000 Hz
per IEC 68-2-6
1
1
Individual specifications as per
Balluff factory standard
7.1 Dimensions, weights, ambient
conditions
• Nominal length
< 4000 mm
• Dimensions pages 4 and 5
• Weight approx. 1.4 kg/m
• Housing anodized aluminum
• Housing attachment:
Mounting clamps with isolation
bushings and screws
• Operating temp. –40 °C to +85 °C
• Humidity < 90%, non-condensing
• Protection class per IEC 529 IP 67
when closed up
7.2 Supply voltage (external)
Regulated supply voltage
BTL5-_1... DC 20 to 28 V
Ripple
< 0.5 V
pp
BTL5-_2... DC ±14.7 to ±15.3 V
Current draw < 90 mA (at 1 kHz)
Inrush < 3 A/0.5 ms
Polarity reversal protection built-in
Overvoltage protection
Transzorb diodes
Electric strength
GND to housing 500 V
Control arm (optional)
BTL2-GS08-_ _ _ _-A
Aluminum, dimensions
Fig. 3-
8
Various standard lengths LS
available (please specify when
ordering)
7.7 Accessories (optional)
Connectors Fig. 4-1
7.8 Compatible processors and
... for BTL5-P1
Analog output processor cards:
BTA-A 0...10 and 10...0 V
BTA-C 0...20 or 20...0 mA *
BTA-E 4...20 or 20...4 mA *
BTA-G -10...10 and 10...-10 V
* also: 0...10 V and 10...0 V
Digital output processor cards:
BTA-D11 20 bit, binary
BTA-S11 16 setpoint outputs
BTA-H11 22 bit,
BCD, Gray/binary or
SSD, Gray
BTA-V11 Velocity output card
Parallel, digital and analog output
Displays:
BDD-07-9 digital display, 7-digit
for BTA-H, BTA-S and BTA-V
BDD-AM10-1-P display and
controller with 2 relay outputs
BDD-CC08-1-P display and
controller with 8 setpoints
7.3 Control signals
INIT pulse
Level +5 V RS 485/422 driver
Length 1 µs (max. 3 µs)
Pulse lengths over 3 µs
can damage the unit.
Shielded cable,
max. length 500 m, Ø 6 to 8 mm.
7.5 Included in shipment
Transducer Fig. 3-1
or Fig. 3-5
(with mounting brackets,
isolation bushings and screws,
not incl. magnet)
7.6 Magnets (order separately)
• Spacing, offset and installation
pages 4 and 5
Operating temp. –40 °C to +85 °C
BTL5-P-3800-2 Fig. 3-2
Weight approx. 12 g
Housing plastic
BTL5-P-5500-2 Fig. 3-3
Weight ca. 40 g
Housing plastic
Non-linearity:
Nom. length < 500 mm > 500 mm
±150 µm ±0.03 % FS
BTL5-P-4500-1 Fig. 3-4
Weight approx. 90 g
Housing plastic
Operating temp. –40 °C to +60 °C
BTL5-F-2814-1S Fig. 3-6
Weight approx. 28 g
Housing plastic
BTL5-M-2814-1S Fig. 3-7
Weight approx. 32 g
Housing anodized
aluminum
Contact surface plastic
BTL5-N-2814-1S Fig. 3-7
Weight approx. 35 g
Housing anodized
aluminum
Contact surface plastic
7.4 Connection to processor
displays
To Next Page
