12 english
6.1 Accuracy
The specifications are typical values for BTL7-V50T... at
24V DC and room temperature, with a nominal length of
500 mm in conjunction with the BTL5-P-3800-2,
BTL5-P-4500-1, BTL5-P-5500-2
1)
, BTL6-A-3800-2
1)
,
BTL6-A-3801-2
1)
, BTL5-F-2814-1S, BTL5-T-2814-1S,
BTL5-M-2814-1S or BTL5-N-2814-1S.
The BTL is fully operational immediately, with full accuracy
after warm-up.
For special versions, other technical data may
apply.
Special versions are indicated by the suffix -SA
on the part label.
Position resolution 1µm
Non-linearity with a constant distance
between the magnet and profile:
Nominal length ≤5500mm
Nominal length >5500mm
±30µm
±0.02%FS
Hysteresis ≤±10µm
Repeat accuracy ≤±5µm
(typ. ±2.5µm)
Temperature coefficient
2)
≤18ppm/K
Velocity resolution 0.1mm/s
Min. detectable velocity 1mm/s
Max. detectable velocity 10m/s
6.2 Ambient conditions
3)
Operating temperature −40°C to +85°C
Storage temperature −40°C to +100°C
Relative humidity <90%, non-condensing
Shock rating
per EN60068-2-27
4)
150g/6ms
Continuous shock
per EN60068-2-29
4)
150g/2ms
Vibration
per EN 60068-2-6
4)
20g, 10 to 2000Hz
Degree of protection per
IEC60529
Connector C003 (when
attached)
IP67
6.3 Supply voltage (external)
Voltage, stabilized
5)
10 to 30VDC
Ripple ≤0.5V
SS
Current draw (at24VDC) ≤120 mA up to 1524 mm
≤160 mA from 1525 mm
Inrush current ≤500mA/10ms
Reverse polarity protection Up to 36V
Overvoltage protection Up to 36V
Dielectric strength
(GND to housing)
500VAC
6.4 Output
Short-circuit resistance Signal cable to GND
6.5 Dimensions, weights
Housing height 36.8mm
Nominal length 50 to 7620mm
Weight (depends on length) Approx. 1.4kg/m
Housing material Anodized aluminum
6.6 Maximum sampling rate f
max
At nominal length
0050 to 0250mm
0251 to 0600mm
0601 to 1300mm
1301 to 2700mm
2701 to 5500mm
5501 to 7600mm
>7601mm
780Hz
710Hz
600Hz
460Hz
245Hz
180Hz
170Hz
1)
In the position range 0 to 20mm, the specified linearity limit can be
exceeded by ±100 µm.
2)
Nominal length=500mm, magnet in the middle of the measuring range
3)
For : Use in enclosed spaces and up to a height of 2000m above sea
level.
4)
Individual specifications as per Balluff factory standard
5)
For : The transducer must be externally connected via a limited-
energy circuit as defined in UL61010-1, a low-power source as defined in
UL60950-1, or a class 2 power supply as defined in UL1310 or
UL1585.
6
Technical data
BTL7-V50T-M ____ -P-C003
Micropulse Transducer in a Profile Housing
