Bandit 2550 - Page 97

Bandit
93
Copyright 4/21
MODELS 2550/2550T
Make sure to order components according to tting type, ttings may vary on all components.NOTICE
Hydraulic components, ttings, hoses will vary depending on optional equipment.
Order by physical description.
2550T - REMOTE CONTROLS
# Part Number Description
1 See pp 78-79 Hydraulic Tank
2
900-3951-31 In Tank Filter (Start 11/12)
900-3951-32 Filter Element Only (Start 11/12)
900-3938-23 In Tank Filter (Pre 11/12)
900-3938-96 Filter Element Only (Pre 11/12)
3 900-3944-78 Tank Strainer
4
900-3982-94 Cutter Wheel Pump (Start 1/17)
900-3955-97 Cutter Wheel Pump (Pre 1/17)
5
900-3955-82 High Pressure Filter
900-3944-57 Filter Element Only
6
900-3959-06
Cutter Wheel Motor
(Start 4/14)
900-3951-17 Cutter Wheel Motor (Pre 4/14)
900-3955-99
Cutter Wheel Motor Manifold
Relief
900-3956-04 Relief Only
7 See Check Sheet Auxiliary Pump
# Part Number Description
8
900-3960-10 Remote Manifold Assembly
900-3945-71
Swing/Travel Control (NV-1,
NV2)
900-3929-09
Drive/Swing Counter Balance
(CBV-A, CBV-B)
900-3934-53
Solenoid & Cartridge (SV-BL,
SV-HL, SV-SW, SRV-P1, SV-
LT, SV-RT)
900-3952-66
Relief (RV-BL, RV-HL, RV-SW,
RV-P2)
9 900-3952-11 Oil Cooler
10 900-3940-29 Cutter Wheel Lift Cylinder
11 900-3946-87 Grading Blade Cylinder
12 900-3958-80 Swing Cylinder
13 900-3959-99 Left Track Motor
14 900-3959-99 Right Track Motor
HYDRAULIC DIAGRAM
