Bandit 490 - Chipper Components

Bandit
Copyright 11/10 PAGE 41
MODEL 490 CHIPPER COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 932-3000-09 Drum Scrapper - Right Side
2. See Page ?? Anvil
3. 932-3000-10 Drum Scrapper - Left Side
4. 932-3000-26 Bearing Backer Plate
5 a. 900-1916-52 Chipper Drum Bearing
b. 900-4912-37 Bearing Bolt (1/2”-13NC x 1” SHCS)
6. 900-1916-70 Bearing Cover
7. 626-300068 Drum Head Lock Pin
8. 900-2921-55 Infeed Hopper Limit Switch
9 a. 932-2000-02 Chipper Drum Head Assembly
b. 932-2000-10 Chipper Drum Head Assembly - PTO
c. See Page ?? Chipper Knife & Hardware
10. 932-3000-11 Top Base Cover
11. 932-2000-04 Transition Assembly
12. 932-3000-21 Top Discharge Clamp
13. 932-3000-22 Top Discharge Clamp
14 a. 932-2000-05 Discharge Assembly
b. 932-3000-24 Flipper Only
c. 900-7900-93 Rubber Cap (Not Shown)
15. 900-4915-76 Discharge Lock Knob
16. 932-3000-40 Beltshield Back
17. ** Engine Sheave
18. ** Engine Sheave Bushing
19. ** Chipper Belt
20 a. 932-2000-07 Beltshield Assembly (Includes #16)
b. 932-2000-11 Beltshield Assembly - PTO
21. ** Chipper Sheave Bushing
22. ** Chipper Sheave
** Components vary with engine options order by physical description or machine S/N.
NOTICE Nuts, bolts, washers, and all other components can be ordered by physical description.
