Bandit 490 - Chipper Knife & Hardware

Bandit
Copyright 11/10 PAGE 42
MODEL 490 CHIPPER KNIFE & HARDWARE
KNIFE BOLTS MUST BE INSTALLED THROUGH KNIFE AS SHOWN
Part Numbers For Model 490 Knives
LOCATION PART NUMBER DESCRIPTION
3. 900-9901-68 Knife Saver Kit (Not Shown)
4. 900-9901-65 File For Knife Saver Kit Only (Not Shown)
5. 900-9901-63 Replacement Blades For Knife Saver (Not Shown)
Part Numbers For Miscellaneous Knife Parts
NOTICE Parts may not be exactly as shown.
LOCATION PART NUMBER DESCRIPTION
1. 900-9908-62 1/4” x 2 1/16” x 15 3/4” Chipper Knife
2. 900-4915-61 3/8”-16NC x 1” BHCS Knife Bolt
NOTICE Torque Knife Bolts to 28 - 30 ft.-lbs. (38 - 40 Nm)
