Bandit
Copyright 11/10 PAGE 43
MODEL 490 ANVIL HARDWARE
NOTICE Parts may not be exactly as shown.
LOCATION PART NUMBER DESCRIPTION
1. 932-3000-05 Anvil Only
2. 900-4906-65 3/8” Flat Washer
3. 900-4906-62 3/8” Lock Washer
4. 900-4906-54 3/8”-16NC x 3/4” Hex Head Bolt
5. 981-1006-16 Anvil Gauge
6. 932-2000-08 Anvil & Hardware Kit (Includes 1 - 4)
NOTICE Torque Anvil Bolts to 26 - 30 ft.-lbs. (36 - 40 Nm)
