Copyright 11/10 PAGE 47
MODEL 490 FRAME & ACCESSORY COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 932-2000-15 Tongue Tube Assembly
2. 900-4908-00 Hitch Pin & Clip
3. 900-5910-19 Tongue Jack
4 a. 900-4912-36 Safety Chain With Hooks & Spring Latches
b. 900-4913-11 Hook For Safety Chain
5. 900-5904-67 2” Ball Coupler
6. 900-5909-82 9” x 3.50”-4” Flat Free Smooth Tire
7. 932-2000-17 Single Castor Wheel Mount
8 a. 932-2000-18 Mount Bar For Castor Wheels
b. 900-4915-50 Nylon Bushing
9. 900-5910-10 480 x 8” Tire And 5-Bolt Rim
10 a. 900-5905-37 Axle Spindle & Hub
b. 021-041-01 Grease Cap For Hub
c. 085-001-00 Rubber Plug For Grease Cap
d. 031-031-02 Inner & Outer Bearing For Hub
e. 031-031-01 Inner & Outer Bearing Cup For Hub
f. 010-060-00 Inner & Outer Seal For Hub
g. 900-5905-97 1/2”-20NF Stud Only
11. 900-6911-34 340 CCA Battery
12. 900-7901-35 Plastic Battery Box for 340 CCA Battery
13 a. 900-6913-94 1.25 Gallon Fuel Tank With Cap
b. 900-3907-67 Tank Cap Only
c. 900-6913-96 Fuel Tank Shut Off
d. 900-6913-95 Grommet For Fuel tank
14 a. 900-6914-01 Tiny Tach
b. 900-6914-02 Mufer
c. 900-6914-03 Mufer Guard
15. -- Engine Adjuster
NOTICE Nuts, bolts, washers, and all other components can be ordered by physical description.
