Copyright 11/10 PAGE 49
MODEL 490
LOCATION PART NUMBER DESCRIPTION
1 a. 900-1903-25 6 Spline Adaptor - 1 3/8” Dia. Shaft To 1 3/8” Dia. 6 Spline
b. 980-0113-54 21 Spline Adaptor - 1 3/8” Dia. Shaft To 1 3/8” Dia. 21 Spline
2. 932-3000-64 PTO Jack Shaft - 1 3/8” Diameter
3 a. 900-1901-96 PTO Jack Shaft Bearing - 1 3/8” Diameter
b. 900-4903-17 1/2”-13NC x 2 1/2” Hex Head Bolt (Bearing Bolt - Adjuster Side)
c. 900-4900-74 1/2”-13NC x 2” Hex Head Bolt (Bearing Bolt - Non Adjuster Side)
d. 900-4906-86 1/2” Lock Washer
e. 900-4906-88 1/2” Flat Washer
f. 900-4906-82 1/2” Hex Nut
4. 900-4902-29 Jack Shaft Adjuster
5. 932-3000-68 Jack Shaft Cover Plate
6. ** PTO Sheave
7. ** PTO Sheave Bushing
8. 932-2000-11 Beltshield Assembly - PTO
9. ** Chipper Belt
10. ** Chipper Sheave Bushing
11. ** Chipper Sheave
12 a. 932-2000-10 Chipper Drum Head Assembly - PTO
b. See Page ?? Chipper Knife & Hardware
13 a. 900-4902-41 Bottom Lift Pin - 7/8”
b. 900-4902-38 7/16” Lynch Pin
14 a. 900-4902-39 Top Lift Pin - 3/4”
b. 900-4902-38 7/16” Lynch Pin
15. 900-6902-20 Yoke For Slip Clutch - 1 3/8” Diameter Shaft
16. 900-6902-21 Clutch Pack For Slip Clutch
NOTICE Nuts, bolts, washers, and all other components can be ordered by physical description.
PTO COMPONENTS
** Components vary with engine options order by physical description or machine S/N.
