Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
71 2 Far Frequency 32-bit integer The frequency corresponding to a
target at the far limit of the sensing
range
100 Hz – 45000 Hz
600 Hz rw y
72 Display String
72 1 Line 1 5-octet String
US_ASCII
ro
73-75
unused/reserved
76 All-Time Run Time Event
Time
76 1 Event Time 32-bit integer 0–2147483647 0 rw y
77 Resettable Run Time Event
Time
77 1 Event Time 32-bit integer 0-2147483647 0 rw y
IO-Link Events
Events are acyclic transmissions from the IO-Link device to the IO-Link master. Events can be error messages and/or warning or
maintenance data.
Code Type Description
25376 (0×6320) Error Parameter error (check datasheet and values)
36000 (0×8CA0) Warning All-time Run Time Event (Event indicating the corresponding configured running time has elapsed.)
36001 (0×8CA1) Warning Resettable Run Time Event (Event indicating the corresponding configured running time has
elapsed.)
36003 (0×8CA3) Notification Teach Completed Event (Event indicating a teach has been completed.)
36004 (0×8CA4) Notification Factory Settings Restored Event (Event indicating that the factory settings have been restored.)
36005 (0×8CA5) Notification Teach Coerced Event (Event indicating a taught condition resulting in a setpoint being coerced.
Taught was updated.)
36007 (0×8CA7) Notification Teach Failed Event (Event indicating an invalid target condition was attempted to be taught. Taught
setpoint was not updated.)
36096 (0×8d00) Error Laser fault event (laser shut down for safety)
36097 (0×8D01) Error System Fault Event (Contact Banner Engineering to resolve.)
IO-Link Data Reference Guide: Q5X Sensor
©
Banner Engineering Corp. All rights reserved
