Banner Q5X Reference Guide

Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
65 4 BDC1 BGS Teach Offset
Mode
8-bit integer
0 = Auto
1 = User Selected
0 rw y
65 5 BDC1 FGS Window Size
Mode
8-bit integer
0 = Auto
1 = User Selected
0 rw y
65 6 BDC1 User Teach Offset 16-bit integer -1905 mm – 1905 mm 0 mm rw y
65 7 BDC1 FGS User Window
Size
16-bit integer 0 mm – 1905 mm 0 mm rw y
65 8 BDC1 Auto Thresholding 8-bit integer
0 = On
1 = Off
2 = High Speed
1 rw y
66 BDC2 Vendor Specific
Configuration
rw
66 1 BDC2 Delay Mode 8-bit integer
0 = Disabled
1 = On/Off Delay
2 = Oneshot
3 = Totalizer
0 rw y
66 2 BDC2 Delay Time 1 32-bit integer 0–90000 ms 0 ms rw y
66 3 BDC2 Delay Time 2 32-bit integer 0–90000 ms 0 ms rw y
66 4 BDC2 BGS Teach Offset
Mode
8-bit integer
0 = Auto
1 = User Selected
0 rw y
66 5 BDC2 FGS Window Size
Mode
8-bit integer
0 = Auto
1 = User Selected
0 rw y
66 6 BDC2 User Teach Offset 16-bit integer -1905 mm – 1905 mm 0 mm rw y
66 7 BDC2 FGS User Window
Size
16-bit integer 0 mm – 1905 mm 0 mm rw y
66 8 BDC2 Auto Thresholding 8-bit integer
0 = On
1 = Off
2 = High Speed
1 rw y
67 Status
67 1 Measurement Value (distance
in mm)
32-bit integer ro
67 2 Excess Gain Percent 32-bit integer ro
67 3 Stability 8-bit integer
0 = No target
1 = Marginal/Multiple Peaks
2 = Stable
ro
67 4 Multiple Peak State 8-bit integer
0 = Multiple Peaks Not Present
1 = Multiple Peaks Present
ro
67 5 Emitter Status 8-bit integer
0 = Active
1 = Inactive
ro
67 6 Laser Fault Status 8-bit integer
0 = Not Present
1 = Laser Fault Present
ro
67 7 BDC1 Totalizer Counts 16-bit integer ro
67 8 BDC2 Totalizer Counts 16-bit integer ro
68 unused/reserved
69 All-Time Run Time
69 1 Run Counter 32-bit integer ro
70 Resettable Run Time
70 1 Run Counter 0 rw
71 Pulse Frequency
Configuration
71 1 Near Frequency 32-bit integer The frequency corresponding to a
target at the near limit of the
sensing range
100 Hz – 45000 Hz
100 Hz rw y
IO-Link Data Reference Guide: Q5X Sensor
6 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 206834 Rev. B
