Index Sub-
index
Name Length Value Range Default Access
Rights
Data
Storage?
Smart Sensor
Profile?
AOI
63 2 BDC2 Mode 8-bit integer
1 = One-Point BGS
128 = Two-Point Static BGS
129 = Dynamic BGS
130 = One-Point Window (FGS)
131 = Dual Teach
128 rw y y
63 3 BDC2 Hysteresis 16-bit integer 0 mm – 2000 mm 0 rw y y
64 Configuration
64 1 Response Speed 8-bit integer 0 = 3 ms
1 = 5 ms
2 = 10 ms
3 = 25 ms
4 = 50 ms
3 rw y
64 2 Gain 8-bit integer
0 = High excess gain mode
1 = Standard excess gain mode
0 rw y
64 3 Secondary Output Function 8-bit integer
0 = Remote Teach Input
1 = Laser On
2 = Master
3 = Slave
4 = Complementary Ouput
5 = Laser Off
6 = Pulse Frequency Modulation
7 = Independent Output
7 rw y
64 4 Zero Reference Location 8-bit integer
0 = Near
1 = Far
0 rw y
64 5 Shift Zero Reference After
Teach
8-bit integer
0 = Off
1 = On
0 rw y
64 6 Display Read 8-bit integer
0 = On
1 = On + Inverted
2 = Off
3 = Off + Inverted
0 rw y
64 7 Pushbutton Lockout 8-bit integer
0 = No Lockout
1 = Pushbuttons Locked
2 = Operator Lockout
0 rw y
64 8 Output Polarity 8-bit integer 0 = Default,
1 = PNP
2 = NPN
0 rw y
64 9 IOL Filter Time 16-bit integer 0 ms – 65535 ms 0 rw y
64 10 Includes Binary Data in
Process Data
8-bit integer 0 = Include
1 = Don't Include
0 rw y
64 11 Process Data Measurement
1 Selection
8-bit integer 0 = Disabled
1 = Excess Gain
2 = Excess Gain / 10
3 = Channel 1 Dual Mode Percent
1 rw y
64 12 Process Data Measurement
2 Selection
8-bit integer 0 = Disabled
1 = Distance Measurement Value
2 = Displayed Distance
Measurement Value
3 = Channel 2 Dual Mode Percent
1 rw y
65 BDC1 Vendor Specific
Configuration
65 1 BDC1 Delay Mode 8-bit integer
0 = Disabled
1 = On/Off Delay
2 = Oneshot
3 = Totalizer
0 rw y
65 2 BDC1 Delay Time 1 32-bit integer 0–90000 ms 0 ms rw y
65 3 BDC1 Delay Time 2 32-bit integer 0–90000 ms 0 ms rw y
IO-Link Data Reference Guide: Q5X Sensor
P/N 206834 Rev. B www.bannerengineering.com - Tel: + 1 888 373 6767 5
