Banner QS30 Series User Manual

QS30 Series Diffuse-Mode Laser Sensor
10 P/N 109027 rev. C
Banner Engineering Corp. •
Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Quick-Disconnect Cables
38 mm max.
(1.5")
M12 x 1
ø 15 mm
(0.6")
38 mm max.
(1.5")
Style Model Length Dimensions
5-pin
Euro-style
straight
MQDC1-506
MQDC1-515
MQDC1-530
2 m (6.5')
5 m (15')
9 m (30')
M12 x 1
ø 15 mm
(0.6")
44 mm max.
(1.7")
White Wire
Blue Wire
Black Wire
Brown Wire
Gray Wire
Pin-out
5-pin
Euro-style
right-angle
MQDC1-506RA
MQDC1-515RA
MQDC1-530RA
2 m (6.5')
5 m (15')
9 m (30')
