Banner QS30 Series User Manual

P/N 109027 rev. C 11
QS30 Series Diffuse-Mode Laser Sensor
Banner Engineering Corp. •
Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
SMBQS30Y
Other Compatible Mounting Brackets:
• SMB30MM
• SMB30SC
• SMB30A
16.35 mm
(0.64")
24.0 mm
(0.94")
35.0 mm
(1.38")
13.3 mm
(0.52")
26.5 mm
(1.04")
18.0 mm
(0.71")
56 mm
(2.20")
7.0 mm
(0.28")
33 mm
(1.30")
17.0 mm
(0.67")
M18 X 1
4 X Ø 3.3 mm
(0.13")
2 X R 33.0 mm
(1.30")
SMBQS30L
• 14-gauge, stainless steel right-angle bracket for
cable models
• Clearance for M4 (#8) hardware
• ± 12° tilt adjustment
• Heavy-duty die-cast bracket
• M18 vertical mounting option
• ± 8° tilt adjustment with cabled units
• Nuts and lockwasher included
SMBQS30LT
• 14-gauge stainless steel for QD models with right-
angle cables
• Tall right-angle mounting bracket
• ± 8° Tilt adjustment
64.4mm
[2.54"]
1.9mm
[0.07"]
4.5mm
[0.18"]
24.0mm
[0.95"]
11.0mm
[0.43"]
ø4.3mm
[ø0.17"]
44.0mm
[1.73"]
22.0mm
[0.87"]
24°
R35.0mm
[R1.38"]
59.4mm
[2.4"]
R33.0mm
[R1.3"]
20°
33.0mm
[1.3"]
4.5mm
[0.18"]
24.0mm
[0.95"]
11.0mm
[0.43"]
ø4.3mm
[ø0.17"]
44.0mm
[1.73"]
R35.0mm
[R1.38"]
1.9mm
[0.07"]
22.0mm
[0.87"]
16°
R1.7mm
[R0.07"]
R33.0mm
[R1.3"]
91.4mm
[3.60"]
86.4mm
[3.4"]
20°
Brackets
