Banner QS30 Series User Manual

P/N 109027 rev. C 9
QS30 Series Diffuse-Mode Laser Sensor
Banner Engineering Corp. •
Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
33.0 mm
(1.30")
12.5 mm
(0.49")
3.5 mm
(0.14")
44.0 mm
(1.73")
1.3 mm
(0.05")
22.0 mm
(0.87")
13.0 mm
(0.51")
5.0 mm
(0.20")
CLASS 1 LASER PRODUCT
Complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant
to Laser Notice No. 50, dated 7-26-01.
32.5 mm
(1.28")
35.0 mm
(1.38")
QS30LD
QS30LD
10-30 VDC
10-30 VDC
2 x ø3.3 mm (0.125")
max. torque
0.7 Nm (6 in lbs)
M30 x 1.5 Thread
max. torque
6 Nm (53 in lbs)
with included 30 mm
mounting nut
Dimensions
QD Models
Cabled Models
Hookups
Cabled Models
QD Models
bn
Remote
Teach
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load
150 mA max. load
bn
Remote
Teach
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load
150 mA max. load
