4.7.3 Outline and instructions of meter
Compact meter engineered by SME
Hand brake switch, lamp lights when pulling the hand brake
With safety seat switch open, meter indicates seat symbol, main
contactor can’t be connected and truck can’t travel until seat switch
closes.
Turning angle, indicating the position of rear wheel
Maintenance time indication
Remind the users to maintain and service the forklift truck.
Slow-speed operating
With the lamp on, the traveling speed and lifting speed will be
reduced in slow-speed mode.
Traveling speed (Indicated by 0-9 forms)
Overheated motor temperature warning
