baracuda Captura Plus - Default Chapter; Table of Contents

The BARACUDA
®
Captura Plus is suitable for most domestic in-ground pools up to 10m x 5m.
Pool surfaces include: Concrete, pebblecrete, quartzon, fibreglass and vinyl. Not suitable for tile pools.
Not suitable for above ground pools. Suitable for medium to large debris.
YOUR CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY INSTALLED AND TO
PROVIDE LOW MAINTENANCE OPERATION. A WARRANTY CARD IS SUPPLIED IN THE BOX. PLEASE GO
TO BARACUDA.COM.AUTO REGISTER FOR WARRANTY.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required, please
contact your original dealer. If the original dealer does not perform warranty service, please visit
www.baracuda.com.au to locate an independent service company near you. If you are unable to locate a service
company,please call our Baracuda Customer Service at 1300 784 423.
Section 1. Important Safety Instructions ....... 3
Section 2. Getting Started ............................... 4
2.1 GeneralSpecications ..................................... 4
2.2 Unpacking ......................................................... 4
2.3 Cleaner Control box .......................................... 4
2.4 Assembling the Transport Caddy ...................... 5
2.5 Connecting the Control Unit to the Caddy ......... 6
2.6 Connecting the Floating Cable to
the Control Box .................................................. 7
Section 3. Operation ........................................ 8
3.1 Submerging the Cleaner ................................... 8
3.2 Starting the Cleaner .......................................... 9
3.3 Wall Climbing
(Surface Control System) .................................. 9
3.4 Stopping the Cleaner
and Removing from the Pool ............................. 9
3.5 Rinsing the Cleaner ......................................... 10
3.6 Cleaning the Filter Canister ............................. 10
3.7 Storing the Cleaner ........................................ 11
Table of Contents
Section 4. Maintenance ................................. 12
4.1 Cord Tangling .................................................. 12
4.2 Replacing the Brushes .................................... 13
4.3 Replacing the Track ......................................... 14
Section 5. Troubleshooting .......................... 16
5.1 Using the Information LED .............................. 15
5.2 General Troubleshooting .................................16
Section 6. Conformity ................................... 17
Introduction
Congratulations on the purchase of your new BARACUDA
®
Captura Plus
™
robotic pool cleaner. Your Captura
Plus is designed and manufactured for easy installation, and years of carefree operation. Before installing the
cleaner, please take a few moments to become familiar with its components and to review the items listed under
Important Information
.
2 H670900_REVA
Suitable Pools
