3.1 Projector source and control connections
3.1.1 Input source connections
The source switching time is variable and could take few seconds..
Source signal connectivity
The connector panel at the back of the projector is used for all source connections.
Source signal connectivity on the projector is:
• 2x Dual Link DVI-I (DVI-D functionality)
• 2x DisplayPort 1.2
• 1x HDMI 2.0
• 1x HDBaseT
3.1.2 Connector Specifications
3.1.2.1 Specifications DVI-I inputs
Specifications
Parameter Value
Connector DVI- I female digital RGB ( DVI-D functionality)
Signal characteristics DVI 1.0, Digital, TMDS
Max. cable length 25 m (24 AWG)
Max. pixel rate 330 MHz (dual link), 165 MHz (single link)
Scan format Progressive
Max. input data resolution 1920x1200 60Hz (Single link)
2560x1600 60Hz (Dual Link)
1920x1200 @120 Hz (Dual link)
1920x2400 @60Hz
Bit depth 8 bit
EDID Supported
HDCP Supported
3.1.2.2 Display Port 1.2
Specifications
Parameter Value
Connector Standard Display port
Signal characteristics DP 1.2
Functionality Mandatory
Max. cable length 2 m (24 AWG) - RBR;
2 m (24 AWG) – HBR1, HBR2
Supported Link Rate RBR, HBR1, HBR2
Scan format Progressive
