Barco Bragi

33R5911698 /07 Bragi
Parameter Value
Max. input data resolution 2560x1600@120Hz WQXGA / 3840x2400 @60Hz
(4K ) Max
Bit depth 8, 10, 12 bit
EDID Supported
HDCP Supported
3.1.2.3 Specifications HDMI 2.0
Specifications
Regarding HDMI 2.0: The decryption protocol HDCP 2.2 are enabled and valid in this unit.
Parameter Value
Connector Standard HDMI
Signal characteristics Digital, TMDS
Max. cable length 2 m (24 AWG)
Max. pixel rate 594 MHz
Max. input data resolution 3840x2160 @60Hz
Bit depth 8, 10, 12 bits
EDID Supported
HDCP Supported
Ethernet No
Audio return No
HDCP Supported
3.1.2.4 Specifications HDBase T input
The HDBaseT standard allows the link to also be used as a regular network port. In addition to
carrying video data, it can also be connected to regular ethernet network without carry out any video
data.
Due to limitations in the projector and network standards, only the LAN and the HDBaseT should be
used for network traffic, but not both simultaneously. If both are connected simultaneously it might
lead to undefined behavior where traffic is not being sent on the link indicated by the IPaddress.
This is only valid when the projector has a firmware version 2.1 or higher installed.
Specifications
Parameter Value
Reference specification HDBaseT 1.0 Specification, June 2010
Connector Standard RJ-45, 8P8C
Signal characteristics HDBaseT
Max. cable length (1080p/48b/60Hz) 100 m (Cat5e/6), Pixel Clock <=225HHz, Video
Datarate <=5.3Gbps
70 m (Cat5e/6), Pixel Clock >225HHz, Video
Datarate >5.3Gbps
Getting the projector started
