5. Advanced operation
5.11 Lu minance t arget
About the luminance target
The luminance target of your Coronis 3MP LED Display is adjustable over a predefined range. When you
change the luminance target, the display will adjust its backlight to reach the target.
To set the luminance target:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration menu.
3. Enter the Luminance Target submenu.
4. Set a luminance target value as desired and confirm.
The default, factory DICOM calibrated luminance value is availa ble in the technical spec-
ifications table. The guaranteed backlight li fetime is valid for this setting.
5.12 Viewing m o des
About viewing modes
The Coronis 3MP LED Display can be used in two viewing modes:
Diagnostic This mode provides the full calibrated luminance
and is intended for using the display for diagnostic
purposes.
Text In this mode, the luminance is reduced to
approximately half of the luminance. This
is intended for using the display with office
applications such as word processing.
Please note that text mode is not persistent, once
powered off, the unit will restart in diagnostic mode.
To quickly switch the viewing mode without having to enter the OSD menu, touch the
left and right key (the two leftmost buttons) at the same time during normal ope ration.
As the Coronis 3MP LED Display is intended to be used in a diagnostic environment,
the diagnostic mode should always be selected.
To select a viewing mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration menu.
3. Enter the Viewing Mode submenu.
4. Select Diagnostic/Text as desired and confirm.
K5902060 CORONIS 3MP LED DISPLAY 01/10/2015
23
