Coronis 5MP 17
8 Retain the clip for possible further transportations.
9 Now that the height-positioning is unlocked, you can adjust the
position of the displays.
Figure 10: Adjust display position
When both displays are not correctly aligned, minor corrections
are possible in relative height and relative angle, by loosening
and tightening the opposite pairs of allen screws (opposite
sides or opposite diagonals) of the positioning sliders.
