Table of contents
TABLE OF CONTENTS
1. DP4K-L series accessory kit .................................................................. 3
1.1 Kit content ..................................................................................................... 3
1.2 Installation process ........................................................................................... 5
1.3 Assembling the support frame............................................................................... 6
1.4 Installing the support frame for hoses upwards............................................................ 7
1.5 Installing the support frame for hoses downwards ........................................................ 8
1.6 Installing insulation shells projector side hoses upwards ................................................. 9
1.7 Installing insulation shells projector side hoses downwards..............................................10
1.8 Installing insulation shells on the chiller side...............................................................11
1.9 Installing the plastic catch basin.............................................................................12
1.10 Installing the castor wheels ..................................................................................13
R5905882 DP4K-L ACCESSORY KIT 06/09/2017
1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Barco DP4K-60L and is the answer not in the manual?

Barco DP4K-60L Specifications

General IconGeneral
Projector native resolutionDCI 4K (4096x2160)
AC input voltage200 - 240 V
Power consumption (max)6700 W
Service life of light source30000 h
Weight and Dimensions IconWeight and Dimensions
Depth1445 mm
Width744 mm
Height706 mm
Weight235000 g
