Barco DP4K-60L User Manual

1. DP4K-L series accessory kit
1. DP4K-L SERIES ACCESSORY KIT
Purpose of this upgrade kit
This accessory kit may only be used to support and isolate the coupling of the hoses of the projector.
Where to use
There exist two accessory kits for the DP4K-L series. One for the DP4K-22L and DP4K-30L and one for
the DP4K-45L and DP4K-60L. For ordering numbers see Barco website w
ww.barco.com.
About this document
This document gives a brief introduction of the accessory kit and explains with detailed step by step in-
structions how to install the insulation shells and the hoses support assembly. The latest version of this
document can be downloaded from the Barco website w
ww.barco.com.
WARNING: The procedures below may only be performed by Barco trained and qualified
technicians.
Overview
•Kitcontent
• Installation process
• Assembling the support frame
• Installing the support frame for hoses upwards
• Installing the support frame for hoses downwards
• Installing insulation shells projector side hoses upwards
• Installing insulation shells projector side hoses downwards
• Installing insulation shells on the chiller side
• Installing the plastic catch basin
• Installing the castor wheels
1.1 Kit conten t
In the box:
• Insulation shells hoses upwards projector rear-left side (1 set, reference 1 image 1-1)
• Insulation shells hoses downwards projector rear-left side (1 set, reference 2 image 1-1)
• Insulation shells hoses upwards/downwards projector rear-right side (1 set, reference 3 image 1-1)
R5905882 DP4K-L ACCESSORY KIT 06/09/2017
3

Barco DP4K-60L Specifications

General

Projector native resolution	DCI 4K (4096x2160)
AC input voltage	200 - 240 V
Power consumption (max)	6700 W
Service life of light source	30000 h

Weight and Dimensions

Depth	1445 mm
Width	744 mm
Height	706 mm
Weight	235000 g
