2. General
Situation Solution
Multiple disks failed (multiple red LEDs) + RAID
broken.
Note: The disk status (RAID broken) can be
retrieved via the (Web) Commander. See user
guide of the (Web) Commander.
1. Switch off the power.
2. Replace all defect HDDs with original HDD
spare parts. See procedure "Removing a HDD
from the ICMP", page 71, and "Installing a
HDD into the ICMP", page 72. Ensure to insert
the HDDs firmly.
3. Switch on the power.
4. Start “RAID Initialize”. See user guide of the
Communicator.
Result: a new empty RAID is created.
All HDD LEDs remain off + Error 10580 “local
storage not a vailable”.
Note: The disk status (Error code) can be
retrieved via the (Web) Commander. See user
guide of the (Web) Commander.
1. Switch off the power.
2. Reseat all HDDs. See procedure "Removing a
HDD from the ICMP", page 71, and "Installing
a HDD into the ICMP", page 72. Ensure to
insert t he HDDs firmly.
3. If problem remains try “RAID Initialize”. See
user guide of the Communicator. Note that all
content will be lost!
4. If problem remains contact Service for further
instructions.
In case the ICMP has to b e returned to factory (e.g. for repair) the non defective HDDs
should be removed and kept.
2.4 Introduction of ICMP battery
Functionality of battery
The battery is used to maintain the security data necessary to decoding in real-time the Digital Cinema
files. If the battery is disconnected or discharged, this data will definitely be lost. In this case, the only
possibility way to recover the functionality of the card is the return it to the manufacturer.
Locate the batt ery
The battery is located at the rear upper left side of the ICMP assembly. Once the ICMP assembly removed
from the projector, flip the board upside-down, and place the back of the board in front of you.
10
R5906594 ICMP 09/11/2016
