5. ICMP service procedure
5. Insert the piece of plastic tube on the positive connector of the other slot (the old battery).
Image 5-17
6. You can use the insulated flat screwdriver to help you to release the old battery.
Caution: Be very careful not to touch the two connectors (positive / negative) in the battery slot with the
battery or any other metallic objects. A short circuit between the two connectors would cause
immediate failure of the card.
Image 5-18
7. Remove the piece of plastic tube.
Only the new battery remains. The other slot must be empty.
R5906594 ICMP 09/11/2016
77
