Installation
18
Figure 8
Cable routing
Routing the signal cables
• Bind the cables in the connector compartment together with the
cable tie inside the connector compartment.
• Put the connector compartment cover back on the display. Pay
attention that the signal cables are positioned under the bulge
in the cover.
Attaching the display to an arm stand
The panel is compatible with the VESA 100 mm standard. So it can be
used with an arm stand according to the VESA 100 mm standard.
Important:
• Use an arm that is approved by VESA (according to the VESA 100
mm standard).
• Use an arm that can support a weight of at least 13 kg (28.66
lbs).
1)
PC
To Next Page
