Barco Nio Color 2MP 23" - 2.3 Display position adjustment

2. Installation
Image 2-4
3. Connect the mains power input to a grounded power outlet.
Image 2-5
4. If necessary for your application, earth the Nio Color 2MP 23" by connecting the earth pin to a grounded
outlet by means of a yellow/green AWG18 wire (maximum a
dmitted cable length according to national
regulation requirements).
Image 2-6
5. Route all cables through the provided cable routing clip at the back of the display stand.
2.3 Display position a djustment
To adjust the display position
You can safely tilt, raise and l
ower the display as desired.
K5902134 NIO COLOR 2MP 23" 05/07/2017
9
