Installing your Barco display controller
Nio display systems 25
Note: To use multiple BARCOMED PCIe display controllers in a
single host, you need to enable VGA on only ONE of the B
ARCOMED
PCIe display controllers and disable VGA on ALL the other
BarcoMed display controllers. To use a B
ARCOMED PCIe display
controller with a third party VGA controller or with one or more
B
ARCO MXRT display controllers, do NOT enable VGA on the
B
ARCOMED PCIe display controller.
Which PCIe slot to use
The table on the preceding page lists the different model display
controller(s) available for your B
ARCO NIODisplay System and the
recommended PCIe slot to use for optimum performance. Figure 5
shows the three different types of PCIe slots.
Figure 5: Examples of PCIe slots
x16 slot
x8 slot
x1 slot
