PGXG-61B/PGWX-61B/PGWU-61B - - 2014/02/12
3. Installation
1
3 245
6
+12V Relay Output
Network Port
7
1
Power Cord
2
12V DC Jack
3
RS232 Cable
4
VGA in Cable
5
HDMI Cable
6
Network Cable
7
VGA out Cable
3.3.2 Connecting to a Computer or Laptop
Wiring Diagram
