203R5911443 /11 UDM
Refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160 / 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 Mhz
Software tools Projector Toolset + Android** app + iOS** app
Control XLR wired + IR, RS232, Wifi**, GSM**
Network connection 10/100 base-T, RJ-45 connection, Wifi**
Power requirements 120-160 V (max 70% brightness) 18.5A / 200-240V (+/- 10%), 13.5A, 50-
60Hz
Max. power consumption 1900W nom/ 2200w max @ 230 volts ECO STBY<2W
1300W nom/ 1530w max @ 120 volts ECO STBY<2W
Noise level (typical at 25°C/
77°F)
49 dB(A)
Operational ambient
temperature
0-40°C / 32°-104°F ***
Operational humidity 0-80% (non condens)
Dissipation BTU Max. TBD BTU/h
Dimensions (WxLxH) 725 x 540x 339 mm / 28.54 x 21.26 x 13.3'
Shipping Dimensions incl. pallet
(WxLxH) 850 x 665 x 613 mm / 33.46 x 26.18 x 24.13 inches
Weight 48 kg (105lbs) / shipping weight from factory: 61 kg (134.5 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
*Note *Brightness levels +/- 10%
** Wifi and GSM options are not available in all countries. Check with your
Barco representative for more info.
***at higher altitude light output might be dimmed
A.2 Specifications for UDM W30
Specifications
Notes
Projector type WUXGA 3-chip DLP digital projector
Technology 0.96" DMDTM x3
Resolution 1,920 x 1,200
Brightness 26,000 ansi lumens/ 27,000 center lumens / 30,000 ISO lumens*
Contrast ratio Full field 2200:1 / Barco Dyna Black 20000:1
Brightness uniformity 93%
Specifications
