Bard CH3S1 - Figure 5 Electric Heat Clearance

Manual 2100-455A
Page 12 of 25
FIGURE 5
ELECTRIC HEAT CLEARANCE
RECOMMENDED
1" OPTIONAL CLEARANCE
Duct
Outside Sheeting
Unit
Inside Sheeting
Wall Frame
Supply Air
Typical Building
Supply Air Duct
Flange of Wall
MIS-2210
Side section view of supply air
duct for wall mounted unit showing
0" clearance to combustible surfaces.
Note: This unit is approved for 0" clearance, but the optional 1" clearance is recommended. See Figures 3 & 4.
