Manual 2100-746
Page 39 of 55
4 Generator Run Alarm bit 0 (OFF) - 1 (ON)
5 Theft Alarm bit 0 (OFF) - 1 (ON)
6 Emergency Ventilate Alarm bit 0 (OFF) - 1 (ON)
7
Local Temperature/Humidity Sensor
Disconnect
bit 0 (OFF) - 1 (ON)
8 High Humidity Alarm bit 0 (OFF) - 1 (ON)
9 Low Humidity Alarm bit 0 (OFF) - 1 (ON)
100 System 1 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)
101 System 1 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)
102 System 1 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)
103 System 1 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)
105 System 1 - G - Blower bit 0 (OFF) - 1 (ON)
106 System 1 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)
107 System 1 - A Terminal bit 0 (OFF) - 1 (ON)
108 System 1 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)
109 System 1 - H - Humidifier bit 0 (OFF) - 1 (ON)
110 System 1 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)
111 System 1 - Change Filter bit 0 (OFF) - 1 (ON)
112 System 1 - Power Loss bit 0 (OFF) - 1 (ON)
113 System 1 - Compressor Lockout bit 0 (OFF) - 1 (ON)
114 System 1 - Dust bit 0 (OFF) - 1 (ON)
200 System 2 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)
201 System 2 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)
202 System 2 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)
203 System 2 - Y2 - Compressor - Stage 2 bit 0 (OFF) - 1 (ON)
205 System 2 - G - Blower bit 0 (OFF) - 1 (ON)
206 System 2 - O/B - Reversing Valve bit 0 (OFF) - 1 (ON)
207 System 2 - A Terminal bit 0 (OFF) - 1 (ON)
208 System 2 - D - Mechanical Dehum bit 0 (OFF) - 1 (ON)
209 System 2 - H - Humidifier bit 0 (OFF) - 1 (ON)
210 System 2 - AUX - Auxiliary Terminal bit 0 (OFF) - 1 (ON)
211 System 2 - Change Filter bit 0 (OFF) - 1 (ON)
212 System 2 - Power Loss bit 0 (OFF) - 1 (ON)
213 System 2 - Compressor Lockout bit 0 (OFF) - 1 (ON)
214 System 2 - Dust bit 0 (OFF) - 1 (ON)
300 System 3 - W1 - Electric Heat - Stage 1 bit 0 (OFF) - 1 (ON)
301 System 3 - W2 - Electric Heat - Stage 2 bit 0 (OFF) - 1 (ON)
302 System 3 - Y1 - Compressor - Stage 1 bit 0 (OFF) - 1 (ON)
