TROUBLESHOOTING
Manual 2100-746
Page 52 of 55
Temperature Resistance
F C Ω
-40 -40 188,500
-38.2 -39 178,500
-36.4 -38 169,000
-34.6 -37 160,200
-32.8 -36 151,900
-31 -35 144,100
-29.2 -34 136,700
-27.4 -33 129,800
-25.6 -32 123,300
-23.8 -31 117,100
-22 -30 111,300
-20.2 -29 105,700
-18.4 -28 100,500
-16.6 -27 95,520
-14.8 -26 90,840
-13 -25 86,430
-11.2 -24 82,260
-9.4 -23 78,330
-7.6 -22 74,610
-5.8 -21 71,100
-4 -20 67,770
-2.2 -19 64,570
-0.4 -18 61,540
1.4 -17 58,680
3.2 -16 55,970
5 -15 53,410
6.8 -14 50,980
8.6 -13 48,680
10.4 -12 46,500
12.2 -11 44,430
14 -10 42,470
15.8 -9 40,570
17.6 -8 38,770
19.4 -7 37,060
21.2 -6 35,440
23 -5 33,900
TABLE 7
10K OHM NTC
Sensor: Temperature/Resistance
Temperature Resistance
F C Ω
24.8 -4 32,440
26.6 -3 31,050
28.4 -2 29,730
30.2 -1 28,480
32 0 27,280
33.8 1 26,130
35.6 2 25,030
37.4 3 23,990
39.2 4 23,000
41 5 22,050
42.8 6 21,150
44.6 7 20,300
46.4 8 19,480
48.2 9 18,700
50 10 17,960
51.8 11 17,240
53.6 12 16,560
55.4 13 15,900
57.2 14 15,280
59 15 14,690
60.8 16 14,120
62.6 17 13,580
64.4 18 13,060
66.2 19 12,560
68 20 12,090
69.8 21 11,630
71.6 22 11,200
73.4 23 10,780
75.2 24 10,380
77 25 10,000
78.8 26 9,630
80.6 27 9,280
82.4 28 8,940
84.2 29 8,620
86 30 8,310
87.8 31 8,010
Temperature Resistance
F C Ω
89.6 32 7,730
91.4 33 7,450
93.2 34 7,190
95 35 6,940
96.8 36 6,700
98.6 37 6,470
100.4 38 6,250
102.2 39 6,030
104 40 5,830
105.8 41 5,630
107.6 42 5,440
109.4 43 5,260
111.2 44 5,080
113 45 4,910
114.8 46 4,750
116.6 47 4,590
118.4 48 4,440
120.2 49 4,300
122 50 4,160
123.8 51 4,030
125.6 52 3,900
127.4 53 3,770
129.2 54 3,650
131 55 3,540
132.8 56 3,430
134.6 57 3,320
136.4 58 3,220
138.2 59 3,120
140 60 3,020
141.8 61 2,930
143.6 62 2,840
145.4 63 2,750
147.2 64 2,670
149 65 2,590
150.8 66 2,510
152.6 67 2,440
Temperature Resistance
F C Ω
154.4 68 2,360
156.2 69 2,300
158 70 2,230
159.8 71 2,160
161.6 72 2,100
163.4 73 2,040
165.2 74 1,980
167 75 1,920
168.8 76 1,870
170.6 77 1,820
172.4 78 1,770
174.2 79 1,920
176 80 1,670
177.8 81 1,620
179.6 82 1,580
181.4 83 1,530
183.2 84 1,490
185 85 1,450
186.8 86 1,441
188.6 87 1,370
190.4 88 1,340
192.2 89 1,300
194 90 1,270
195.8 91 1,230
197.6 92 1,200
199.4 93 1,170
201.2 94 1,140
203 95 1,110
204.8 96 1,080
206.6 97 1,050
208.4 98 1,020
210.2 99 1,000
212 100 970
Checking Remote Temperature Sensor
(P/N 8301-095) Outside Unit Circuit
1. Disconnect temperature sensor from board.
2.
Use an ohmmeter to measure the resistance of the
sensor. Also use ohmmeter to check for short or open.
3. Check resistance reading to chart of resistance.
Use sensor ambient temperature. (Tolerance of part
is ±1%.)
4. If sensor resistance reads very low, sensor is
shorted and will not allow proper control.
5. If sensor is out of tolerance, shorted, open or reads
very low ohms, it should be replaced.
