2100-444-003A
Page 5
1.6 Model Nomenclature
TCS2 2 - H D M - 001
BASIC MODEL SOFTWARE
REVISION NUMBER ---- REMOTE COMMUNICATIONS
SENSORS DISPLAY M - With
H- Humidity & Temperature D - With X - Without
T - Temperature Only X – Without E - Ethernet
2.0 SPECIFICATIONS
2.1 Electrical Specifications
Supply Voltage 208/240 VAC +/- 10% 50/60 HZ
Minimum Circuit Ampacity 3 Amp
Overcurrent Protection Internal Circuit Breaker - 3 Amp
Controller Analog Inputs 16
Resolution 8 bits/ 0.4% Full Scale
Voltage Range 0 Vdc to +10 Vdc
Current Rating 5.0 mA at +10 Vdc
Binary Relay Outputs 12
Type Form "A" Relay SPST N.O.
Contact Rating 24 VAC, 5 A Resistive
24 VAC, 2 A Inductive
2.2 Mechanical Specifications
Height 26.25 in., (667 mm.)
Width 17.00 in., (432 mm.)
Depth 5.50 in., (140 mm.)
Material 18 ga galvanized steel with Beige baked polyester enamel.
Mounting Vertical
Mounting Area Required 27 in. high by 18 in. wide, (686 mm. high by 457 mm. wide)
Weight 27 lb., (12.3 kilograms)
2.3 Environmental Specifications
Operating Temperature Range 32 to 130
o
F (0 to 55
o
C)
Operating Humidity Range 10 to 95%, non condensing
Storage Temperature Range -35 to 180
o
F (-37 to 82
o
C)
Storage Humidity Range 5 to 95%, non condensing
