61-101-00802.EF2 (REV. G) CH. 1
January 7, 2015 Page 1 of 44
CHAPTER 1 DESCRIPTION
A. Capabilities
(1) Complete testing of fuel quantity system.
(2) Testing of individual fuel tanks.
(3) Testing of indicators.
(4) Dry and wet tank calibration.
B. Panel Controls
(1) See Instruction Manual 56-101-00850 for details on the DC400A Fuel
Quantity Test Set. See Technical Manual 57-101-00800 for information
on the DC400 Digital Fuel Quantity Test Set.
(2) Refer to Aircraft Maintenance Manual for description of the aircraft fuel
quantity system.
C. Aircraft System Description
(1) Refer to the Aircraft Maintenance Manual for specific procedures and
maintenance practices.
D. Equipment Required (or equivalent)
(1) DC400A Digital Fuel Quantity Test Set, P/N 101-00850 or the DC400
Digital Fuel Quantity Test Set, P/N 101-00800
(2) Barfield Instruction Manual 56-101-00850 (DC400A) or Barfield
Technical Manual 57-101-00800 (DC400)
(3) Fuel Quantity Adapter Module, P/N 101-00802
(4) Probe Adapter Cable, Barfield P/N 101-00829 or 101-00814
(5) Test leads, banana plug to alligator clip, P/N 101-01012
(6) 15-pin adapter cable, Barfield P/N 101-00831 or 101-00817
NOTE: Barfield adapter cables are available as a separate
purchase.
(7) A 1900/1900C/1900D Beech Probe adapter pin
(8) A 28 VDC Power Supply
(9) A Probe Selector Unit:
For 1900/1900C, UA and UB: P/N 114-389001/935
For 1900C/1900D (UC, UE): P/N 118-389004/935
