barfield DC400A - Probe Capacitance Full (in Pf)

61-101-00802.EF2 (REV. G) CH. 2
January 7, 2015 Page 19 of 44
AIRCRAFT 1900/1900C, UA and UB
TANK UNIT BEECH PROBE P/N MIN NOM MAX
Integral Outboard 114-389001-29, -31 26.4 29.36 32.3
Integral Inboard 114-389001-25, -27 31.2 34.68 38.1
Integral Combined 114-389001-25, -27 or –29 and -31 57.6 64.04 70.4
Leading Edge
Outboard
114-389001-1, -3 32.1 35.65 39.2
Leading Edge
Inboard
114-389001-9, -11 40.3 44.77 49.2
Box Section 114-389001-13, -15 24.4 27.19 29.9
Center Section
Outboard
114-389001-5, -7 39.1 43.46 47.8
Center Section
Inboard
114-389001-21, -23 29.1 32.35 35.6
Collector Tank 114-389001-17, -19 10.5 11.71 12.9
Table 6 Probe Capacitance Full (in pF)
AIRCRAFT 1900C/1900D, UC and UE
TANK UNIT LOCATION
WING STATION
BEECH PROBE P/N (Ragen P/N) MIN NOM MAX
41.85 118-389004-41 (75-134-9) 66.0 66.5 67.0
79.65 118-389004-43 (75-134-10) 48.2 48.7 49.2
124.59 118-389004-45 (75-134-11) 13.8 14.3 14.8
135.86 118-389004-13 (75-134-4) 90.5 91.0 91.5
171.29 118-389004-47 (75-134-12) 42.2 42.7 43.2
194.85 118-389004-21 (75-134-6) 43.0 43.5 44.0
223.49 118-389004-25 (75-134-7) 52.6 53.1 53.6
276.01 118-389004-49 (75-134-13) 50.5 51.0 51.5
Table 7 Probe Capacitance Full (in pF)
