barfield DC400A - AIRCRAFT 1900;1900 C, UA and UB; AIRCRAFT 1900 C;1900 D, UC and UE; Probe Capacitance Empty (in Pf)

61-101-00802.EF2 (REV. G) CH. 2
January 7, 2015 Page 18 of 44
AIRCRAFT 1900/1900C, UA and UB
TANK UNIT BEECH PROBE P/N MIN NOM MAX
Integral Outboard 114-389001-29, -31 17.91 19.90 21.89
Integral Inboard 114-389001-25, -27 20.03 22.25 24.48
Integral Combined 114-389001-25, -27 or –29 and -31 37.94 42.15 46.37
Leading Edge
Outboard
114-389001-1, -3 21.01 23.34 25.67
Leading Edge Inboard 114-389001-9, -11 24.75 27.50 30.25
Box Section 114-389001-13, -15 15.89 17.66 19.43
Center Section
Outboard
114-389001-5, -7 19.82 22.02 24.22
Center Section
Inboard
114-389001-21, -23 14.91 16.57 18.23
Collector Tank 114-389001-17, -19 7.24 8.04 8.84
Table 4 Probe Capacitance Empty (in pF)
AIRCRAFT 1900C/1900D, UC and UE
TANK UNIT LOCATION
WING STATION
BEECH PROBE P/N (Ragen P/N) MIN NOM MAX
41.85 118-389004-41 (75-134-9) 36.6 37.1 37.6
79.65 118-389004-43 (75-134-10) 26.5 27.0 27.5
124.59 118-389004-45 (75-134-11) 6.7 7.2 7.7
135.86 118-389004-13 (75-134-4) 48.2 48.7 49.3
171.29 118-389004-47 (75-134-12) 23.6 24.1 24.6
194.85 118-389004-21 (75-134-6) 23.0 23.5 24.0
223.49 118-389004-25 (75-134-7) 28.6 29.1 29.6
276.01 118-389004-49 (75-134-13) 26.4 26.9 27.4
Table 5 Probe Capacitance Empty (in pF)
