C. Connecting Test Set
(1) Set up the test set (T/S) as shown in Figures 1 and 2.
(2) Connect the test set ACFT connector to the aircraft wiring plug
removed from the indicator.
(3) Connect the test set ACFT connector to the ACFT connector of the
adapter cable.
(4) Do not connect the test set IND connector of the adapter cable.
(5) Do not connect the test set IND connector.
Figure 1 Insulation Test Connector Setup
