61-101-00802.EF2 (REV. G) CH. 2
January 7, 2015 Page 21 of 44
5. INDICATOR TEST
Note: Refer to PRECAUTIONS and PRELIMINARY sections (Chapter 1).
Note: The Indicator Bench Test (Chapter 3, Section 1) may be performed in place
of the Indicator Test.
A. Aircraft Preparation
(1) Disconnect the aircraft battery.
Caution: When lowering or raising the pilot fuel panel, insure aircraft
battery is disconnected.
(2) Access the indicator.
(3) Open the appropriate circuit breakers.
(4) Disconnect the aircraft wiring plug located at the indicator.
B. Test Set Preparation
(1) Set the ON/OFF switch to OFF.
(2) Rotate the TEST FUNCTION switch to CAP SIM CAL (NORM SYS).
(3) Set the INSULATION/SYSTEM switch to SYSTEM.
(4) Set the MAIN/TOT-AUX/NAC switch to MAIN/TOT.
(5) Set the 200 (pF)/1000 (pF) switch to 200 (pF).
C. Connecting Test Set
(1) Determine the number of pins on connector. Connect test set as
shown in Figure 9 or Figure 10 accordingly.
