61-101-00802.EF2 (REV. G) CH. 3
January 7, 2015 Page 44 of 44
(20) Set the CAP SIM (pF) 100’s and the 10’s to the digits required to
adjust the test set display to an AUX/NAC nominal value referenced
in Table 2.
(21) Press and hold PRESS TO READ CAP (pF) pushbutton while
adjusting CAP SIM (pF) control knob to obtain the test set AUX/NAC
nominal value reading for the aircraft listed in Table 2.
(22) Release the pushbutton.
(23) Rotate the TEST FUNCTION switch to IND AMP.
(24) Verify the indicator shows zero lbs.
(25) If indicator reading is not acceptable, use the EMP 2/E 2 adjustment
(located at the rear of the indicator) to obtain the correct reading.
(26) Repeat steps (2) through (25) until an accurate calibration is
obtained.
(27) Set the test set switch to OFF.
E. Disconnecting or Reconfiguring
(1) Open the circuit breakers.
(2) Disconnect the test set ACFT connector from the aircraft wiring plug
or adapter cable;
(3) Disconnect the test set IND connector from the indicator or adapter
cable.
(4) If applicable, disconnect the adapter cable from the aircraft wiring.
(5) Connect the aircraft wiring plug to the indicator.
(6) Return the aircraft to its original configuration.
