Bartec Syscom MR3000 Series User Manual

13
Figure 2.4.2. Internal view of the MR3000SB with DC power and relay terminals.
2.4.1. Internal display
The LCD of the MR3000SB shows the most important settings and parameters. In particular, there
are two types of screen, that are changing constantly. The first one, as can be seen in Figure
2.4.3a, indicates general parameters related to the MR3000SB:
LINE 1. Typology of the instrument, together with the battery voltage
11
9
7
6
4
3
1
2
5
