Bartell SP8 - Sp8 Gas Parts List

SURFACE PREPARATION SYSTEM OWNER’S MANUAL & PARTS BOOK
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
- 17 -
U
ITEM NO PART NO DESCRIPTION (SP8 GAS ASSEMBLY) QTY REMARK
01 30290 SPS HANDLE ASSM 1 06-23-2004
02 50444 EXHAUST CAP 1
03 30284 SHCS, M10-1.5x25MM 6 06-23-2004
04 11621 LOCKWASHER, M10 12 06-23-2004
05 30289 WASHER, M10 4 06-23-2004
06 30213 DRIVE SPINDLE (PART OF ITEM 92) 1 06-23-2004
07 30245 BEARING COVER PLATE (PART OF ITEM 92) 1 06-23-2004
08 50544 FELT WASHER LARGE (PART OF ITEM 92) 1
09 50004 BEARING (PART OF ITEM 92) 1
10 50545 FELT WASHER SMALL (PART OF ITEM 92) 1
11 10208 KEY - 3/16" SQ x 1-1/2" 1
12 30280 SHSS, M8-1.25x10MM 2 06-23-2004
13 30212 PULLEY - DRIVE 1 06-23-2004
14 30246 RING SPACER (PART OF ITEM 92) 1 06-23-2004
15 50012 SNAP RING (PART OF ITEM 92) 1
16 11747 HHCS, M8-1.25x16MM 2
17 11614 LOCKWASHER, M8 10
18 11667 WASHER, M8 6
19 50522 BELT GUARD 1
20
31222 BELT – 10X660Li 2
50523 BELT – 3VX280 2 04-24-2011
21 30281 HHCS, M6-1.0x25MM 3 06-23-2004
23 30218 KEY - 8MM SQ x 30MM (PART OF ITEM 92) 1 06-23-2004
24 30214 PULLEY - DRIVEN 1 06-23-2004
25 30282 SHCS, M10-1.5x20MM 6 06-23-2004
26 30292 DRIVE FLANGE (PART OF ITEM 92) 1 06-23-2004
27 50357 FRONT WHEEL - 4" DIA. 2
28 50510 WHEEL BUSHING 4
29 50351 WASHER, 5/8" 4
30 50348 FRONT AXLE 1
31 50350 SNAP RING - 5/8" EXT. 2
32 30216 HEX DRIVE SHAFT 1 06-23-2004
33 30204 HOUSING 1 06-23-2004
34 31106 SHCS, M8-1.25 x 20 4 06-23-2004
35 50537 GROUND STRAP 1
36 50482 BEARING, HEX ID (PART OF ITEM 93) 1 06-23-2004
36a 50485 FELT WASHER (PART OF ITEM 93) 1
37 30266 END CAP FLANGE (PART OF ITEM 93) ASSM 1 06-23-2004
38 50611 SHAFT GUARD 1
39 50615 END CAP 1
40 30285 SHCS, M10-1.5 x 45MM 2 06-23-2004
41 30286 RUBBER MOUNT 4 06-23-2004
42 30287 SPACER 4 06-23-2004
43 30207 SLIDER NUT 2 06-23-2004
44 30206 MOUNTING PLATE 1
45 50530 LOCKWASHER, 5/16", EXT. C'SUNK 4
46 30291 FHSCS, M8-1.25 x 40MM 4 06-23-2004
47 10452 HHCS, M8-1.25 x 40MM 4 06-23-2004
48 21333 ENGINE, HONDA GX160 1
92 30250 DRIVE FLANGE ASSM (ITEMS 6, 7, 8, 9, 10, 14, 15, 23, 26) 1 06-23-2004
93 30266 END FLANGE ASSM (ITEMS 36, 36a, 37) 1 06-23-2004
SP8 Gas Assembly
