SP8 Air Assembly
ITEM NO PART NO DESCRIPTION (SP8 AIR ASSEMBLY) QTY REMARK
01 30290 SPS HANDLE ASSM 1 06-23-2004
02 50444 EXHAUST CAP 1
03 30284 SHCS, M10-1.5x25MM 6 06-23-2004
04 11621 LOCKWASHER, M10 12 06-23-2004
05 30289 WASHER, M10 4 06-23-2004
06 30213 DRIVE SPINDLE 1 06-23-2004
07 50093 BEARING COVER PLATE 1
08 50544 FELT WASHER LARGE 1
09 50004 BEARING 1
10 50545 FELT WASHER SMALL 1
12 30280 SHSS, M8-1.25x10MM 2 06-23-2004
14 50546 RING SPACER 1
15 50012 SNAP RING 1
16 11747 HHCS, M8-1.25x16MM 2
17 11614 LOCKWASHER, M8 10
18 11667 WASHER, M8 6
19 50522 BELT GUARD 1
20 50523 BELT – 3VX280 1 06-23-2004
21 30281 HHCS, M6-1.0x25MM 3 06-23-2004
23 30218 KEY - 8MM SQ x 30MM 1 06-23-2004
24 30214 PULLEY - DRIVEN 1 06-23-2004
25 30282 SHCS, M10-1.5x20MM 4 06-23-2004
26 30292 DRIVE FLANGE 1 06-23-2004
27 50357 FRONT WHEEL - 4" DIA. 2
28 50510 WHEEL BUSHING 4
29 50351 WASHER, 5/8" 4
30 50348 FRONT AXLE 1
31 50350 SNAP RING - 5/8" EXT. 2
32 30216 HEX DRIVE SHAFT 1 06-23-2004
33 30204 HOUSING 1 06-23-2004
34 31106 SHCS, M8-1.25 x 20 4 06-23-2004
35 50537 GROUND STRAP 1
36 30288 BEARING, HEX ID 1 06-23-2004
36a
50485 FELT WASHER
1
37 30293 END CAP FLANGE 1 06-23-2004
38 50611 SHAFT GUARD 1
39 50615 END CAP 1
40 30285 SHCS, M10-1.5 x 45MM 2 06-23-2004
41 30286 RUBBER MOUNT 4 06-23-2004
42 30287 SPACER 4 06-23-2004
45 50530 LOCKWASHER, 5/16", EXT. C'SUNK 4
46 30291 FHSCS, M8-1.25 x 40MM 4 06-23-2004
47 10452 HHCS, M8-1.25 x 40MM 4 06-23-2004
57 10402 LOCKWASHER, 5/16" 4
58 30142 HHCS, 5/16-18UNC x 3/4" LG 2
