SURFACE PREPARATION SYSTEM OWNER’S MANUAL & PARTS BOOK
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
- 23 -
SP8 Air Assembly (Con’t)
ITEM NO PART NO DESCRIPTION QTY REMARK
61 50105 SWITCH PLATE 1
62 50107 LOCKWASHER, INT. #8 8
63 11035 PHMS, M4-0.7 x 10MM LG 4 06-28-2011
67 50377 GAST 8 AIR MOTOR 1
68 50380 MUFFLER 1
69 50309 KEY, 3/16" SQ x 1-1/4" 1
70 50117 SHSS,5/16"-18UNCx1/2"LG 2
71 50532 PULLEY - DRIVE 1
72 50551 SLIDING NUT, AIRMOTOR 2
73 50516 MOUNTING PLATE 1
74 50180 MOTOR HOSE - 6" 1
75 50161 HOSE CLAMP, 1/2" 6
76 30008 HHCS, 5/16-18UNC x 1-3/4" 4
77 50163 HOSE FITTING, 1/2" 5
78 10392 HHCS, 1/4"-20 x 3/4" 2 06-28-2011
79 50363 LOCKWASHER, 1/4" 6 06-28-2011
80 11043 WASHER, 1/4" 2 06-28-2011
81 50117 FITTING, 90 DEG. ELBOW, 1/4NPT 1
82 50175 1/4" NIPPLE 1
83 50176 GAUGE 1
84 50494 AIR REGULATOR 1
85 50493 REGULATOR BRACKET 1
86 50165 VALVE CLAMP 2
87 10582 NUT, SQUARE, 1/4-20UNC 2
88 50164 BALL VALVE 1/2" 1
89 50170 REGULATOR HOSE 20" 1
90 50162 EXTENSION HOSE 30" 1
91 50160 QUICK COUPLING 1/2" 1
92 30250 DRIVE FLANGE ASSM (ITEMS 6, 7, 8, 9, 10, 14, 15, 23, 26) 1 06-23-2004
93 30266 END FLANGE ASSM (ITEMS 36, 36a, 37) 1 06-23-2004
