Bartell SP8 - Rear Wheel Assembly (Figure 5)

SURFACE PREPARATION SYSTEM OWNER’S MANUAL & PARTS BOOK
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
- 26 -
URear Wheel Assembly - 30310
Figure 5 – Rear Wheel Assembly
ITEM NO PART NO DESCRIPTION (REAR WHEEL ASSEMBLY) QTY REMARK
201 50350 SNAP RING 1 06-23-2004
202 50351 WASHER - 5/8" 4 06-23-2004
203 50510 WHEEL BUSHING 4 06-23-2004
204 50356 REAR WHEEL - 5" DIA. 2 06-23-2004
205 50349 REAR AXLE 1 06-23-2004
206 30297 LIFT PLATE 1 06-23-2004
