SURFACE PREPARATION SYSTEM OWNER’S MANUAL & PARTS BOOK
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
- 25 -
UHandle Assembly - 30290
ITEM NO PART NO DESCRIPTION QTY REMARK
101 30294 HAND KNOB 1 06-23-2004
102 30295 SPRING PIN, M5 x 48MM 1 06-23-2004
103 30210 BEARING 1 06-23-2004
104 21727 SHCS,M6-1 x12MM 1 06-23-2004
105 30209 BUSHING 1 06-23-2004
106 50266 WAVE WASHER 1 06-23-2004
107 10306 WASHER 1 06-23-2004
108 30208 SCREW SHAFT 1 06-23-2004
109 21725 SHCS, M6-1 x 6MM 1 06-23-2004
110 30205 SLIDE BUSHING 1 06-23-2004
111 30302 SPRING PIN, M5 x 35MM 1 06-23-2004
112 30296 CABLE, PITCH CONTROL 1 06-23-2004
113 11802 LOCKNUT, M10-1.5 1 06-23-2004
114 41516 WASHER, M10 1 06-23-2004
115 30310 REAR WHEEL ASSY 1 06-23-2004
116 50025 SNAP RING 2 06-23-2004
117 50026 WASHER - 1/2" 2 06-23-2004
118 50531 PIN, LIFT PLATE 1 06-23-2004
119 30298 SPRING PIN, M8 x 35MM 1 06-23-2004
120 30299 PULLEY 1 06-23-2004
121 30300 SPS HANDLE TUBE 1 06-23-2004
122 30303 STOP SWITCH CORD ASSY 1 06-23-2004
123 11035 SCREW, M4-0.7 x 10MM 2 06-23-2004
124 30301 HANDLE GRIPS 2 06-23-2004
125 30279 HAND KNOB ASSY (ITEMS 101-103, 105-108) 1 06-23-2004
126 30240 CABLE ASSY (ITEMS 110-112) 1 06-23-2004
