SP8 Electric Assembly (Con’t)
ITEM NO PART NO DESCRIPTION (SP8 ELECTRIC ASSEMBLY, CON’T)) QTY REMARK
50 50616
50617
PULLEY – DRIVE (3HP)
PULLEY – DRIVE (2HP)
1
1
51 50524 BELT - 3VX265 2
52 50085 STRAIN RELIEF 2
53 50101 STRAIN RELIEF NUT 2
54 50091 MOTOR CABLE - 51" 1
55 30233 MOUNTING PLATE 1
56 10919 WASHER, 5/16" 4
57 10402 LOCKWASHER, 5/16" 4
58 30142 HHCS, 5/16-18UNC x 3/4" LG 4
59 50106 RHMS, #8-32 x 1/4"LG 4
60
50090 STARTER BOX - 110V (2HP)
1
50187 STARTER BOX - 230V (3HP)
50761 ENCLOSURE – 230V (3HP) (FOR 50760) * 03-08-2011
60a 50760 MOTOR STARTER – 230V (3HP) 1 * 03-08-2011
60b 50762 SEALING KIT (FOR 50761) 1 * 03-08-2011
61 50105 SWITCH PLATE 1
62 50107 LOCKWASHER, INT. #8 8
63 11035 PHMS, M4-0.7 x 10MM LG 4 06-28-2011
64 50092 MOTOR CABLE – 24” 1
66
50087 PLUG – 220V (2HP)
1
50502 PLUG – 110V (2HP)
50592 PLUG – 220V (3HP)
70 50117 SHSS,5/16”-18UNCx1/2”LG 2
92 30250 DRIVE FLANGE ASSM (ITEMS 6, 7, 8, 9, 10, 14, 15, 23, 26) 1 06-23-2004
93 30266 END FLANGE ASSM (ITEMS 36, 36a, 37) 1 06-23-2004
* Serial number 125416 and greater
