Baruffaldi DB-21 - Sequence of operations N° 2 b*

M.DRIVE.DB-21.GEN.ENG
Ed.
2021 Rev.04
Pag. 18 di 31
TURRET
MODEL
1 2 3
TB-TBH
N° pos
4 5 6 Profile 7 8 9 10
TB-TBH 120/160 - - - 8 - -
Voltage Selection
Univ. - -
Drive Set-up
Acquisition
TB-TBH 200/250 - - 12 - Fast -
TB 320 - - 16 - Medium -
TB 400 - 24 Slow
TB 100 - -
TAB
N° pos
4 5
TAB 210/265
4
(if set K3)
- -
TAB 340/440
8
(if set K5)
- -
6
(if set K3)
-
Custom
12
(if set K5)
-
24
(if set K5)
Sequence of operations N°2b*
1. Drive OFF (24Vdc Off)
2. Turret Locked on the first position
4. Select the turret voltage (see operations sequence 1.) , type
and number of positions as the table below
5. Turn ON the drive (auxiliary supply 24V dc)
6. Set to on the dipswitch n°10 and after 5” set them off
7. Make a Zero reference
8. Turret is ready to work
ON OFF
*The drive arrives pre-set for the turret. Perform this procedure only
in case of any error, and contacting Baruffaldi first
