Baruffaldi DB-21 - TB;TBH SERIES (HARTING CONNECTOR)

M.DRIVE.DB-21.GEN.ENG
Ed.
2021 Rev.04
Pag. 9 di 31
4.2 TB/TBH SERIES (HARTING CONNECTOR)
X1
X4
X3
2
X2
Power supply
220Vac +10/15%
400Vac +10/15%
Pmin =2KVA
Auxiliary supply
24Vdc ±10%
Circuit consumption is 500mA.
Total consumption depend of
relais/electrovalve
Electrovalve
Use auxiliary relays to
pilotate the electrovalve.
Imax Output=2,5A
I/O
Digital I/O connect to PLC.
Details at page N°6.
All signals are optoisolated.
After a short circuit is
necessary to switch
off the auxiliary supply
J2
X5
U
V
W
Black U Motor phase
Blue V Motor phase
Pink W Motor phase
Green-Yellow PE Motor phase
White C Shield
Yellow 1 Thermal switch
Yellow 2 Thermal switch
White-Red 3 ref
White-Yellow 4 0 ref
Black 5 0 cos
Red 6 cos
Yellow 7 sin
Blue 8 0 sin
Pink 9 Shield
1
2
3
4
5
6
7
8
9
LI.15
OP
LI.16
OP
+24v
OP
LI.12
LI.13
LI.14
Brown 10 +24V
Blue 11 0V
Black 12 Turret Unlock
Black 13 Turret Lock
Black 14 Zero Sensor
L1
L2
L3
+
-
MOTOR (Shielded Cable (4x1.5mm²))
Serial Port
+24v
OP
LO.15
LO.16
OP
THERMAL SWITCH
TURRET (sensors 24Vdc no pnp LMax=200mA)
Yellow 1 Thermal switch
Yellow 2 Thermal switch
RESOLVER (Shielded Cable 4x(2x0.25mm²))
T1
THERMAL SWITCH
Brown 10 +24V
Blue 11 0V
10
11
1
2
3
4
5
6
7
8
9
21
22
23
18
19
12
13
14
HARTING CONNECTOR (FEMALE) - T1
