To Next PageTo Next PageWhat causes 'zero search in operative mode different from 1' error on Baruffaldi Servo Drives?
The 'zero search in operative mode different from 1' alarm on Baruffaldi Servo Drives activates after the START command, before unlocking the turret when the operation mode is not equal to 2 or the position code is 0. Check the code management of the position in the PLC and the wiring of connector J1.
What to do if Baruffaldi DB-21 Servo Drives turret rotation times out?
If the Baruffaldi Servo Drives turret does not reach the called position within 60 seconds, it may be due to mechanical interferences preventing rotation. Ensure there are no obstructions. Also, check the wired connections between the drive and turret, specifically M1 UVW and J2.
Why Baruffaldi DB-21 Servo Drives shows a positioning error?
A positioning error with Baruffaldi Servo Drives happens at the end of a position inquiry if the turret is locked in a position different from what was expected. The resolver value, based on the acquisition value, differs from the final position resolver. At startup, check that the drive SETUP matches the turret in use (K2/K5/K3). Ensure the dipswitch is properly set according to the turret in use, considering the transmission ratio and number of stations.
How to fix resolver malfunctioning on Baruffaldi DB-21 Servo Drives?
If you encounter a resolver malfunctioning alarm on Baruffaldi Servo Drives, it means the signal from the resolver is either low or absent. Check the wiring of connector J2 and the connections in the terminal block signals on the turret. Inspect the cable for integrity and continuity. Also, ensure that the drive is set to the motor in use.
What to do if Baruffaldi DB-21 calls a non-existing position?
If Baruffaldi Servo Drives requests a position higher than the number of stations provided, check the setting of the dipswitch. Also, check the code management of the position in the PLC, the wiring of connector J1, and reset the drive setup.
How to fix parity error on Baruffaldi DB-21 Servo Drives?
If you encounter a parity error on Baruffaldi Servo Drives before the turret is unlocked when the START command is sent and the parity bit is not set correctly, check the connection J1 pin 23 with the PLC. Ensure that the PLC program correctly handles the parity bit and that there is a delay in the PLC of at least 50ms between setting the position and parity to the START command.
What to do if unlock proximity switch is in short circuit on Baruffaldi DB-21 Servo Drives?
If the unlock proximity switch remains On (Li.12) during the locking sequence on Baruffaldi Servo Drives, check the functionality of the unlock proximity switch.
What to do if zero proximity switch is in short circuit on Baruffaldi DB-21?
If the zero proximity switch (Li.14) is always On on Baruffaldi Servo Drives, check the functionality of the zero proximity switch.
Why Baruffaldi DB-21 Servo Drives turret is not locked at startup?
If the Baruffaldi Servo Drives gives a command for locking the turret at startup, and the lock proximity switch (Li.13) is off, the alarm is activated. Check the functionality of the proximity switch, the hydraulic/pneumatic circuit, and the electrovalve/auxiliary relais connection.
What to do if the Baruffaldi DB-21 Servo Drives turret stays unlocked during locking?
If the Baruffaldi Servo Drives turret remains unlocked (Li.12 = On) after 30 seconds from the locking command (Lo.16) and there is no signal from the lock proximity switch (Li.13), check the functionality of the proximity switch. Also, check the hydraulic/pneumatic circuit and the electrovalve/auxiliary relais connection.
