M.DRIVE.DB-21.GEN.ENG
Ed.
2021 Rev.04
Pag. 3 di 31
DIPSWITCH N° MOTOR TYPE
6
400V 50/60Hz
6
230V 50/60Hz
GENERAL WARNINGS
Before setting at work, carefully read instructions for use and follow them!
Only qualified personnel, that has carefully read instructions, is allowed to operate on tool holder
turrets.
Responsibility and warranty are excluded if:
- Instructions for use are not followed.
- The turret is not operated in a correct way.
- Maintenance is not performed correctly and regularly.
- Functional changes of any type are brought without manufacturer’s consent.
- Original spare parts are not used.
This symbol highlights critical operations:
- a wrong procedure can cause damages to the turret
- nonobservance can determine wrong settings at work
- nonobservance can impair operator’s safety
INSTALLATION WARNING
The Drive is pre-set for an input voltage of 400V.
If might be necessary to switch the input voltage to 220V before to turn ON the
drive/machine follow the instructions at the chapter 9.
ON
OFF
ON
OFF
